SHOUT nano 100 Ruggedized Satellite Tracker
Manufacturer : NAL Research
Services: Iridium Short Burst Data® (SBD®)
-
Low size, weight, & power
-
Ultra-low power consumption
-
Two-way communication
-
Automated location reports
-
Real-time, pole-to-pole coverage
SHOUT nano 100 Ruggedized Satellite Tracker
Manufacturer : NAL Research
Services: Iridium Short Burst Data® (SBD®)
-
Low size, weight, & power
-
Ultra-low power consumption
-
Two-way communication
-
Automated location reports
-
Real-time, pole-to-pole coverage
Discrete Tracking & Communications
SHOUT nano 100 by NAL Research is an IP67-rated, two-way messaging and personal tracking device designed with discretion in mind. Leveraging the reliable Iridium satellite network, this body-worn tracker provides real-time location data, 2-way messaging, and Android or iOS smartphone pairing via Bluetooth®. A color screen displays messages and alerts, enabling SHOUT nano 100 to be used as a standalone device.
Engineered for both military and commercial use, SHOUT nano 100 uses ultra-low power consumption and is capable of sending a tracking report every 60 seconds. Use the emergency alert switch for quick extractions, ensuring asset safety anywhere in the world.
With ultra-low power consumption and an internal rechargeable battery, the rugged NAL SHOUT nano 100 provides long-lasting connectivity to send free-text and canned messages, interface with backend systems for data logging, and use the emergency alert switch for enhanced asset safety.
Features
- Lightweight & Discrete
-
The low-SWaP body-worn tracker and messaging device weighs less than 3 ounces and is 60% smaller than SHOUT ts.
- Versatile
-
Pair SHOUT nano 100 with any Android or iOS smartphone via Bluetooth or use it as a standalone device via the high-resolution touchscreen.
- Ultra-low Power Consumption
-
The low-cost device has a 20-day battery life and internal rechargeable battery via USB-C.
- Enhanced Safety
-
SHOUT nano 100 can send tracking reports every 60 seconds, supports transmission of free or canned messages or positions, and has an emergency alert switch for quick extractions.
- Flexible Data Formatting
-
Choose between NAL Research’s compressed format or PECOS formatting. Data is packed in either standard plain text or 256-bit AES encrypted blocks.
- For Commercial or DoD Use
-
The device can be programmed for either DoD or commercial uses.
Product Specifications and Certifications
| General | |
|---|---|
| Size | 76 x 46 x 18 mm |
| Weight | 85g |
| Operating Temperature Range | -20⁰C to +60⁰C |
| Operating Humidity Range | <75 % RH |
| Durability Standard | MIL-STD-810G / MIL-STD-461E |
| Screen | High-Resolution Color LCD |
- Iridium® certification
- IP-67 rated
